Heavy Duty Tire-type Mobile Crushing Plant

Heavy Duty Tire-type Mobile Crushing Plant

Product Introduction

The Heavy Duty Tire-type Mobile Crushing Plant is a highly flexible, efficient, and cost-effective crushing equipment designed for various on-site crushing operations. Mounted on robust rubber-tyred chassis, this plant integrates feeding, crushing, screening, and conveying processes into one compact unit, offering quick installation, easy transportation, and excellent mobility on roads or construction sites. It is widely used in mining, quarrying, construction waste recycling, and aggregate production industries.

Working Principle

The Tire-type Mobile Crushing Plant works by transporting raw materials through a vibrating feeder into the primary crusher for initial crushing. Depending on the production requirements, jaw crushers, impact crushers, or cone crushers can be installed as the main crusher.

Once the material is crushed, it can be screened by an integrated vibrating screen to separate finished products from oversized materials. Oversized materials are returned to the crusher for re-crushing, while qualified products are discharged through a belt conveyor for further use.

Main Components:

• Vibrating Feeder

• Primary Crusher (Jaw/Impact/Cone)

• Vibrating Screen (Optional)

• Discharge Conveyor

• Control System

• Heavy-duty Tire Chassis

Performance Features

• Excellent Mobility: Equipped with high-strength rubber tires, enabling easy movement between sites without special transportation tools.

• Flexible Configuration: Multiple crushing and screening combinations available to meet diverse production needs.

• Integrated System: Combines feeding, crushing, screening, and conveying in a single unit, reducing setup time and labor costs.

• High Crushing Efficiency: Powerful crushers ensure superior crushing performance and high output.

• Simple Operation: User-friendly control system with optional remote control operation.

• Rapid Installation: Quick site setup, no need for complex foundation work.

• Energy-Saving Design: Optimized structure to minimize energy consumption and maximize productivity.

• Durable Structure: Rugged frame and high-quality components ensure reliable performance even in harsh environments.

✅ Common Models of Tire-type Mobile Crushing Plant
